MIL-T-81527B(AS)

3.4.1.5 Primar y Input power Requirements.

The equipment shall require

power of the following type and shall not exceed the specified amounts.

AC Power: 3-phase$ 115/200V + 5 percent, 380 to 420 Hz,

85 Amperes (A)/Phase

DC Power: 27 + 2 Vdc, 70 A

3.4.1.6 Contents of Unit.

The Table -Rack shall consist of the following

major units:

(a) Support Assembly, RF Section

(b) Bench Assembly, Pallet Section

(d) Indicator Bench

(e) Computer Bench

(f)

Hydraulic Supply

Liquid Cooling System

(g)

(h) Test Accessories

(i) Antenna Support Fixture

Interconnecting Test Harness

(j)

(k) System Harness

3.4.1.6.1 Support Assembly, RF Section.

3.4.1.6.1.1 Function. The RF Section Support Assembly shall mount the

RF Section of the AN/APG-59 Radar Set and shall make it accessible for use

in the fault isolation, adjustment and repair or replacement of defective

circuits, plug-in assemblies, and components of the RF Transmitter

Assembly.
