MIL-S-60828A(MU)
production, including recording data and results therefrom. Recorded data
and results shall be made available to the Government upon request. A new
certification will be required should any changes occur in materials,
manufacturing processes and techniques previously certified.
TABLE IV
REQUIREMENT
TEST PROCEDURE
CHARACTERISTIC
3.1
Applicable drawings
Materials
3.2
Standards, and
Fabrication
3,3.2
General specification (MIL-F-13926)
Specifications
3.3.l(a)
General specification (MIL-O-13830)
4.5 Inspection equipment.- Except as otherwise provided for by the
contract, the contractor shall supply and maintain inspection equipment in
accordance with the applicable requirements of MIL-I-45607,
4.5.1
on equipment.- Where the contract
provided for Government furnished test equipment, supply and maintenance
of test equipment shall be in accordance with the applicable requirements
specified in MIL-I-45607.
4.5.2 Contractor furnished inspection equipment.
4.5.2.1 Government design.- Unless otherwise specified in the
contract, all inspection equipment specified by drawing number in specifi-
cations or SQAP forming a part of the contract shall be supplied by the
contractor in accordance with technical data listed in the List of Inspec-
tion Documents (IEL) when provided with the Technical Data Package (TDP).
4.5.2.2 Contractor design.- The contractor shall provide inspection
equipment compatible with the "Test Methods and Procedures" specified in
4.6 of this-specification and with the "Component Inspection" and "Test
Facilities" requirements of MIL-F-13926. Since tolerance of test equip-
ment is normally considered to be within 10% of the product" tolerance for
which it is intended, this inherent error in the test equipment design
must be considered as part of the prescribed product tolerance limit.
Thus, concept, construction, materials, dimensions and tolerances used in
the design of test equipment shall be so selected and controlled as to
insure that the test equipment will reliably indicate acceptability of a
product which does not exceed 90% of the prescribed tolerance limit, and
permit positive rejection when non-conforming, Construction shall be
such as to facilitate routine calibration of test equipment.
4.5.2.3 Inspection equipment design requirements.- Inspection equip-
ment provided in accordance with 4.5.2.2 shall meet the following require-
ments:
.
9
